XL Reverb Technology
The essence of the M-One XL, the XL Technology, is based on TC's heritage and continual research and development of Reverb technology. XL Reverbs feature new and improved spatial perspectives, across the entire range of Reverb algorithms. The extended range of the 'reverb size' enables extremely wide or narrow spatial imaging, independently of the decay time. By applying 'Reverb size' to both Early Reflections and the Diffused field, the M-One XL achieves any combination from wide spaces with short decay times, to narrow rooms with long decays.

Early Reflections, Diffused Fields & Modulation
The high resolution Early reflections found in other high-end TC reverbs and newly improved Diffused field technology specific to the M-One XL , ensure a natural and clear result that no other processor can offer in this price range. The XL Technology stands out by applying sophisticated modulation patterns, simulating the modulation of a real room, and allowing ranges of modulation from the barely audible real-room modulation to heavy chorusing and detuning reverbs, also simulating the vintage style of reverbs.

Small Room, a Focus
Small Room simulations have been a major focus in the tuning of the XL Reverbs. The Early reflection patterns combined with the new set of Diffused fields, allow realistic simulations of real rooms. Applied to source material, the room simulations will bring clarity and presence to the source. With the flexibility of the XL Technology, Reverbs can be tweaked from virtually transparent Ambience patterns over large Hall reverbs to low-resolution Plates or Spring reverbs.

Flexibility
Use the M-One XL to run two of the best sounding reverbs or other quality effects simultaneously without compromising sound. The Easy Parameter Level gives you more flexibility to create cool effects and the control of important parameters is right at your fingertips.

Technical Specifications

Digital Inpits and Outputs

• Connectors : RCA Phono (S/PDIF)
• Formats : S/PDIF (24 bit), EIAJ CP-340, IEC 958
• Output Dither : HPF/TPDF dither 24/20/16/8 bit
• Sample Rates : 44.1 kHz, 48 kHz
• Processing Delay : 0.1 ms @ 48 kHz
• Frequency Response : DIO DC to 23.9 kHz ± 0.01 dB @ 48 kHz

Analog Inputs

• Connectors : XLR, balanced
• Impedance, Bal / Unbal : 21 kOhm / 13 kOhm
• Max. Input Level : +24 dBu
• Min. Input Level for 0 dBFS : 0 dBu
• Sensitivity @ 12 dB headroom : -12 dBu to +12 dBu
• A to D Conversion : 24 bit, 128 x oversampling bitstream
• A to D Delay : 0.65 ms / 0.70 ms @ 48 kHz / 44.1 kHz
• Dynamic Range : 100 dB typ, 20 Hz - 20 kHz
• THD typ : < 92 dB (0,0025 %) @ 1 kHz
• Frequency Response : +0/-0.1 dB @ 48 kHz, 20 Hz to 20 kHz
• Crosstalk : <-95 dB, 20 Hz to 20 kHz

Analog Outputs

• Connectors : XLR, balanced
• Impedance Balanced / Unbalanced : 40 Ohm
• Max. Output Level : +20 dBu (balanced)
• Output Ranges Balanced 20/14/8/2 dBu Unbalanced : 14/8/2 dBu
• D to A Conversion : 24 bit, 128 x oversampling bitstream
• D to A Delay : 0.63 ms / 0.68 ms @ 48 kHz / 44.1 kHz
• Dynamic Range : 104 dB typ, 20 Hz to 20 kHz
• THD : typ <-94 dB (0.002 %) @ 1 kHz, +20 dBu Output
• Frequency Response : +0/-0.5 dB @ 48 kHz, 20 Hz to 20 kHz <-100 dB, 20 Hz to 20 kHz

Control Interface

• MIDI : In/Out/Thru 5 Pin DIN
• Pedal : 1/4' phone jack

General

• Display : 23 character / 280 icon STN-LCD display
• Dimensions : 19' x 1.75' x 8.2' (483 x 44 x 195 mm)
• Weight : 4.1 lb. (1.85 kg)
• Mains Voltage : 100 to 240 VAC, 50 to 60 Hz (auto-select)
• Power Consumption : <15 W
