Tascam DR-40X

Write your review |

SKU: APA2019-01370

36 Instalments
2 Years Warranty

Four Track Digital Audio Recorder and USB Audio Interface Versatile four-track audio recorder for cinema, music, podcasting and any other application. Easy-to-use compact design with a high-performance feature set and versatile audio I/O, all to produce professional content. Specifications : ...more

36 Instalments
2 Years Warranty

206 €

VAT included and Κανονικά Μεταφορικά

Upon Order

Instalments:

Add to cart

Add to Wishlist

NEED HELP?

Our expert engineers can assist you!

Description

Four Track Digital Audio Recorder and USB Audio Interface

Versatile four-track audio recorder for cinema, music, podcasting and any other application.

Easy-to-use compact design with a high-performance feature set and versatile audio I/O, all to produce professional content.

Specifications :

Recording Media	SD card (64MB to 2GB), SDHC card (4GB to 32GB), SDXC card (up to 128GB)
File System	FAT16/32, exFAT
Recording File Format
WAV / BWF
Sampling Frequency	44.1k / 48k / 96k Hz
Bit-depth	16 / 24-bit
MP3
Sampling Frequency	44.1k / 48k Hz
Recording Bit-rate	32k / 64k / 96k / 128k / 192k / 256k / 320k bps
Playback Bit-rate	32k to 320k bps, VBR, ID3TAG Ver. 2.4
Number of Channels	4-channel (2 Stereo)
Playback speed control	0.5 to 2.0 times (in 0.1 increments) * 44.1k/48kHz only
Built-in Microphone	Unidirectional, Stereo (switchable between A-B and X-Y positions)
EXT MIC/LINE IN
Connector	XLR/TRS Combo jack (1: GND, 2: HOT, 3: COLD)
Nominal Input Level	-19dBV (MIC) / +4dBu (LINE)
Maximum Input Level	-3dBV (MIC) / +20dBu (LINE)
Input Impedance	2.2kΩ (MIC) / 10kΩ (LINE)
PHONES/LINE OUT
Connector	1/8" (3.5mm) Stereo Mini jack (Unbalanced)
for LINE connection
Nominal Output Level	-14dBV (10kΩ load)
Maximum Output Level	+2dBV (10kΩ load)
Output Impedance	12Ω
for Headphones connection
Maximum Output Power	20mW + 20mW (32Ω load)
USB
Connector	USB Micro B-type
Format	USB2.0 HIGH SPEED
Built-in Speaker	0.3W, Mono
Low-cut Filter	40 / 80 / 120Hz
Chromatic Tuner	C1 to B6, A4 = 435Hz to 445Hz (in 1Hz increments)
Effector	6 presets (Hall 1, Hall 2, Room, Studio, Plate 1, Plate 2)
Tripod attachment screw-hole	1/4" Tripod attachment screw-hole
Power	3 AA Batteries, USB bus power, AC 100 to 240V (optional AC Adapter)
Power Consumption	2.5 W (Max)
Battery Operation Time (Recording)
Alkaline (EVOLTA)	approx. 18 hours (2ch WAV, 44.1kHz, 16-bit, using Built-in Microphone, JEITA)
Ni-MH (eneloop)	approx. 16 hours (2ch WAV, 44.1kHz, 16-bit, using Built-in Microphone, JEITA)
Dimensions (W×H×D)	2.75" × 6.1" × 1.37" / 70 × 155 × 35 mm
Weight	8.3 oz. / 213 g

Audio Performance

Frequency Response
Fs 44.1kHz	20Hz to 20kHz, +1/-3dB (EXT IN to LINE OUT, JEITA)
Fs 48kHz	20Hz to 22kHz, +1/-3dB (EXT IN to LINE OUT, JEITA)
Fs 96kHz	20Hz to 40kHz, +1/-3dB (EXT IN to LINE OUT, JEITA)
Total Harmonic Distortion	0.05% or less (Fs 44.1k/48k/96kHz, EXT IN to LINE OUT, JEITA)
Signal-to-Noise Ratio	92 dB or higher (Fs 44.1k/48k/96kHz, EXT IN to LINE OUT, JEITA)
