Sound Devices MixPre-6 II

Write your review |

SKU: APA2021-01061

Δωρεάν Μεταφορικά
36 Δόσεις
2 Έτη Εγγύηση

MixPre-6 II, 4 Preamp, 8 Track, 32-Bit Float Audio Recorder....περισσότερα

Δωρεάν Μεταφορικά
36 Δόσεις
2 Έτη Εγγύηση

1.385 €

Τιμή με Φ.Π.Α και Δωρεάν Μεταφορικά

Κατόπιν Παραγγελίας

Δόσεις:

Προσθήκη στο καλάθι

Προσθήκη στη λίστα επιθυμίας

ΕΧΕΙΣ ΑΠΟΡΙΕΣ;

Οι ειδικοί μηχανικοί μας μπορούν να σε βοηθήσουν!

Περιγραφή
Χαρακτηριστικά

Four ultra-low-noise Kashmir microphone preamps with adjustable limiters capture high quality audio in the field, on set, or with a computer.

Create a mix using the built-in 6 x 2 portable mixer.

Record up to 8 tracks to an SD card and backup to a USB thumb drive.

8-in, 4-out USB audio interface streams to your computer via USB-C at bit depths up to 32-bit float.

Choose bit depths from 16 to 32-bit float, and sampling rates from 44.1 kHz to 192 kHz.

Internal LTC timecode generator. Timecode In/Out via Aux In/Stereo Out.

Timecode and record triggering via HDMI.

USB-A for control surfaces, keyboards, and auto-copy to USB drive.

In-unit ISO mixing, gain, pan, low-cut, phase inversion, and phantom power.

Sunlight-readable color touch screen and LED metering.

Lightweight, durable, and small: perfect for bag use, mobile recording, or a home studio.

Powerful 300 mW+300 mW headphone amp allows clear and accurate reference of audio.

Includes a MX-4AA Battery Sled (batteries not included), MX-PSU AC Power Supply, and USB-C to USB-C cable.

Customize with plugins from the Plugin Store.

Χαρακτηριστικά

Audio Inputs

Frequency Response: 10 Hz to 80 kHz +/- 0.5 dB re 1 kHz @ 192 kHz sample rate
THD + Noise: 0.005% max (@1 kHz, 22-22 kHz BW, gain=20 dB, -10 dBu in)
ADC: 32 bit precision; 142 dB dynamic range min (A-weighted, gain=10 dB, fader=0 dB)
Equivalent Input Noise: -130 dBV (-128 dBu) max (A-weighting, gain=76 dB, 150 ohm source impedance)

Inputs

Mic: XLR active-balanced; 4k input
Line: XLR active-balanced; 4k input
Aux/Mic in: 3.5 mm TRS, 2-channel unbalanced; 2.2k
Line: ¼-inch TRS active-balanced; 4k input
USB Audio: 4 channels
6 Total analog inputs: 4 mic-line inputs, 2 on Aux In
All inputs fully RF-filtered and overload protected.

Gain

Mic input: +6 dB to +76 dB
Line input: -20 dB to +30 dB
Fader: -inf to +20 dB
Headphone: -inf to +20 dB
Total, Mic-to-recording (max): +96 dB
Aux In (Mic): Gain = +10dB to +40 dB
Aux In (Line): Gain = -10dB to +20 dB
Total Aux Gain including Fader (Mic-to-recording): +60 dB

Maximum Input Level

Mic XLR: +14 dBu (limiters on or off)
Line XLR: +28 dBu (limiters on or off)
Aux In (Mic): -10 dBu
Aux In (Line): +10 dBu

Low Cut Filters

40 Hz to 160 Hz (adjustable), 18 dB/oct. First stage analog, subsequent stages digital.

Microphone Powering

Mic XLRs: 48 V via 6.8k resistors, 10 mA each
Mic 3.5 mm: 3 V @ 3k source

Limiters

Limiter at all gain stages, range > 40 dB. First stage analog, subsequent stages digital. Adjustable Threshold, Ratio, and Release.

Audio Outputs

DAC feeding Stereo Out, Headphone Out: 32 bit precision; 115 dB dynamic range (A-weighted)
Stereo Out: 3.5 mm TRS stereo unbalanced, 500 ohm output, +7.8 dBu max output level
Headphones Out: 3.5 mm TRS stereo unbalanced, 300 mW + 300 mW, for use with any impedance headphones

USB

Audio Interface (USB-C): 8-in/4-out; 44.1 to 96 kHz; 16/24/32-bit integer, 32-bit float; Class-compliant USB 2.0 high speed or ASIO® (supplied via download)
Mass Storage (USB-C): USB 2.0 high speed
Keyboard (USB-A): Text entry and control
Thumbdrive (USB-A): Manual or auto-copy to drive
Midi Control Surface (USB-A)

Recording

Maximum Record Tracks: 8 Tracks: Stereo mix + 6 ISOs

Sampling Frequency

44.1 kHz
47.952 kHz
48 kHz
48.048 kHz
96 kHz
192 kHz

Bit Depth

16
24
32 Float

Recording Storage

Type: SD, SDXC, SDHC Card (USB thumbdrive, copy only)
Max Storage Size: 512 GB (SDXC)
Card format: exFAT

File Type

Polyphonic WAV

Timecode

Timecode Modes

Free Run
Time of Day (file stamped w/current ToD)
Rec Run
Ext LTC (file stamped w/incoming LTC on 3.5mm Aux In)
Camera TC (file stamped w/incoming TC from cameras that output TC)

Timecode Frame Rates

Auto-detects (fps):
23.98 (same as 23.976)
24
25
29.97DF
29.97ND
30
30DF

3.5 mm Aux In

Timecode Input
Timecode: 20k ohm impedance, 0.3 V – 3.0 V p-p (–17 dBu – +3 dBu)

3.5 mm Stereo Out

Timecode Output
Timecode: 1k ohm impedance, 3.0 V p-p (+12 dBu)

HDMI

TC Reader via HDMI

Sample/Timecode Accuracy

0.2 ppm (0.5 frames per 24 hours)

Remote Control

Bluetooth LE: Wireless control using Wingman app
HDMI (micro): Auto-record start/stop trigger from cameras that output record flag over HDMI
Timecode: Auto-record start/stop trigger via Aux In timecode

File Delivery to Cloud

Compatible with Viviana Cloud

Touch Screen

320×256; 1.6-inch, color, sunlight-viewable IPS LCD

Power

AA Batteries: 4x AA sled (included); 8x AA sled (optional accessory). NiMH recommended
From computer: Bus-powered via USB-C port; optional MX-USBY cable, connects one USB-C to two USB-A ports
AC Adapter: MX-PSU (included) Power supply wall adapter w/ USB-C connector; 15W; has 4 adapter plugs for US, UK, AU & Europe
L-Mount: Optional sled for 2x (hot-swappable) Sony L-type Li-ion batteries

Environmental
