Manley CHINOOK

Προσθήκη αξιολόγησης

Κωδικός Προϊόντος: APA-2015-60552

Manley CHINOOK

Προσθήκη αξιολόγησης

Κωδικός Προϊόντος: APA-2015-60552

The spawn of the Manley Steelhead - one of the world's greatest phono preamplifiers - Stereophile Class A Recommended Component and The Absolute Sound's Preamp of the Year, has arrived. The Chinook epitomizes the sound of the Steelhead. Designed for the music lover, not the switch tweaker. S.. ...Περισσότερα
2.999,00  Τιμή με ΦΠΑ και Δωρεάν Μεταφορικά

Τιμή Καταλόγου: 3.250,00 €

Κερδίστε: 251,00 € (7.7%)

Κατόπιν παραγγελίας
2999.00 € Τελική τιμή με ΦΠΑ και μεταφορικά
Τιμή Καταλόγου: 3.250,00 €
Κερδίζετε: 251,00 €

Δόσεις:

83.31€ / μήνα
Κατόπιν παραγγελίας
Ειδοποιήστε με όταν υπάρχει σε απόθεμα

The spawn of the Manley Steelhead - one of the world's greatest phono preamplifiers - Stereophile Class A Recommended Component and The Absolute Sound's Preamp of the Year, has arrived. The Chinook epitomizes the sound of the Steelhead. Designed for the music lover, not the switch tweaker.

Setting up the Chinook couldn't be easier. There are two internal settings for optimal gain: 45dB for Moving-Magnet cartridges and 60dB for Moving-Coil cartridges. Set it and forget it! The back panel contains DIP switches for adjusting the input resistive and capacitance loading values. 31 possible options between 26 and 800 Ohms plus 47k Ohms and 7 capacitive loading choices between 50 pF and 350 pF provide flexibility to match any cartridge and fine tune the tone.

Χαρακτηριστικά:

  • Gain: Internal DIP switches select 45dB or 60dB

  • Deviation from RIAA curve: Less than ± 0.5 dB from 20Hz to 20kHz at any gain setting. Typically less than ±1dB from 10Hz to 100kHz.

  • Distortion (THD+N) (47k Ohm Input Termination, 45dB gain, 1kHz sine, 0dBu output): Typical 0.010% THD+N, into 100k Ohm load, BW = 100Hz-22kHz

  • Distortion (THD+N) (47k Ohm Input Termination, 45dB gain, 1kHz sine, 0dBu output): Typical 0.030% THD+N, into 600 Ohm load, BW = 100Hz-22kHz

  • Dynamic Range (MM input, Gain set to 45db, 200 Ohm source): 91dB  1kHz, 0.1% THD+N, BW = 22Hz-22kHz

  • Dynamic Range (MM input, Gain set to 45db, 200 Ohm source): 107dB  1kHz, 1.0% THD+N, BW = 22Hz-22kHz

  • Noise Floor at 45dB gain setting with shorted input: -84 dBu, A-weighted

  • Noise Floor at 60dB gain setting with shorted input: -75 dBu, A-weighted

  • Maximum Input at 45dB gain setting with 20 Ohm Source Z  1kHz into 10 kOhm load: 250mV RMS = +34.5 dBu  1% THD+N BW=22Hz-22kHz

  • Maximum Input at 60dB gain setting with 20 Ohm Source Z  1kHz into 10 kOhm load: 40mV RMS = +34.2 dBu  1% THD+N BW=22Hz-22kHz

  • Maximum Output: +37dBu  1kHz, 1.5% THD+N into 100 kOhm load

  • Output Impedance: 91 Ohms

  • Minimum Recommended Load: 2500 Ohms

  • Internal Power Supply: Fully regulated linear B+, Heater, and control voltage rails.

  • Operating Mains Voltage: Units are built for original destination country's mains voltage: 100V, 120V, or 220-240VAC as indicated on the serial number badge.

  • Power Consumption in Standby mode: 1 Watt (8.0mA  120VAC)

  • Power Consumption: 42 Watts (345mA  120VAC)

  • Mains Voltage Frequency: 50~60Hz

  • Power Transformer: Toroid contruction for low radiation.

  • Mains Fuse for 100V operation:
    800mA SLO-BLO Glass Littlefuse Series 239 size 5mm x 20mm

  • Mains Fuse for 117V-120V operation:
    800mA SLO-BLO Glass Littlefuse Series 239 size 5mm x 20mm

  • Mains Fuse for 220V-240V operation:
    400mA SLO-BLO Glass Littlefuse Series 239 size 5mm x 20mm

  • Standby Transformer Fuse for all voltage operation 100V-240V: 10mA, SLO-BLO, MDL type size 1/4" x 1 1/4"

  • Badge Lamp: LED illumination

  • Dimensions: W=19", L=11", H=3 1/2"

  • Shipping Weight: 15 Lbs.
