Electrocompaniet ECP-2 MKII
SKU: APA2022-11030
-
Δωρεάν Μεταφορικά -
36 Δόσεις
-
2 Έτη Εγγύηση
DESCRIPTIONWith the renewed international enthusiasm for the vinyl format, a world-class phono preamplifier or RIAA stage is more important in a reference setup than ever before.The ECP2-MKII has become a new favorite of reviewers and enthusiasts alike. A benchmark product in its price bracket, much...περισσότερα
-
Δωρεάν Μεταφορικά
-
36 Δόσεις
-
2 Έτη Εγγύηση
2.499 €
Τιμή με Φ.Π.Α και Δωρεάν Μεταφορικά
Κατόπιν Παραγγελίας
Ειδοποιήστε με όταν υπάρχει σε απόθεμα
Προσθήκη στο καλάθι
Προσθήκη στη λίστα επιθυμίας
DESCRIPTION
With the renewed international enthusiasm for the vinyl format, a world-class phono preamplifier or RIAA stage is more important in a reference setup than ever before.
The ECP2-MKII has become a new favorite of reviewers and enthusiasts alike. A benchmark product in its price bracket, much like other Electrocompaniet products.
It incorporates state-of-the-art instrumentation and operational amplifiers and highest quality discrete components in the signal path. Of course it is all DC coupled.
The ECP2-MKII introduces new chassis and front plate design, in line with our other products in the Classic Line.
It will make your vinyl records sing like no other phono preamplifier we know of, and it seems the industry agrees with us.
ADJUSTABLE GAIN
The ECP2-MKII can accommodate any imaginable pickup, MM or MC thanks to its extremely configurable input stage, adjustable gain and the ECP 2 MKII is strictly matched to the RIAA curve.
BALANCED AUDIO
ECP 2 MKII incorporates state-of-the-art instrumentation and operational amplifiers and highest quality discrete components in the signal path. Of course it is all DC coupled.
Χαρακτηριστικά
Phono section
Gain @ 1k Hz RCA: Adjustable 39,8 – 71,4 dB
Gain @ 1k Hz XLR: Adjustable 45,8 – 76,4 dB
Resistance loading (RL): Adjustable 10 Ω – 47 kΩ
Capacitive loading (CL): Adjustable 0 – 350 pF
Maximum output level: 17.5 V rms (+ 25 dB V)
Overload margin> 31 dB @ 1k Hz
Output impedance: 100 Ω single-ended, 200 Ω balanced
Frequency response: 20 – 20k Hz +/- 0.2 dB
RIAA Correction Accuracy: ± 0,1 dB
Subsonic filter: -3dB @ 11 Hz, 24 dB/octave
Channel separation: > 85 dB, 20 – 20k Hz
THD + Noise: < 0.003 % @ 1k Hz
S/N-R: 96 dB, 1k Hz, A-weighted, ref. 10 dB V output
S/N-R: 91 dB, 1 kHz, A-weighted, ref. 5 mV input
S/N-R: 67.4 dB, 1 kHz, A-weighted, ref. 500 μV input
Dimensions
Width: 470 mm / 18.5 in
Depth: 373 mm / 14.6 in
Height: 78 mm / 3 in
Weight: 9 kg / 19.8 lbs
